SKU: 3-14007 Category:

ROBOT 40

Our battery-powered industrial dolly system.

$69,500.00

How to Use a GKS Robot

Why Buy a GKS Robot?

Additional information

Weight950 lbs
Load Capacity

88,000 lbs (40 tons)

Drive

DC Motor
(24 V/ 1.5 kw)

Battery Type

Li-Polymer

Battery Life

4-6 hours

Speed

Min: 10 ft/min Max: 20 ft/min

Incline max**

3%

Loading Height

9.8" (250 mm)

Number of special heavy -duty wheels L-ROBOT

4(drive) + 8(Supporting) (6"/3"/154 + 76 mm wide)

Number of speical heavy-duty wheels F-ROBOT

16 (3" / 76 mm wide)

L-ROBOT Dimensions (L x W x H)

45.4 x 68.8 x 9.8" /
1153 x 1748 x 250 mm

F-ROBOT Dimensions (L x W x H)

17.6 x 63 x 9.8" /
447 x 1600 x 250 mm

Contact Surface L-ROBOT

12.5 x 12.5" / 320 x 320 mm

Contact Surface / Cassette

12.2 – 15" / 310 x 379 mm

Connecting Bar, Adjustable

1.4' – 5.3' (440 – 1600 mm)

L Dolly Weight

1022 lbs. / 460 kg

F Dolly Weight

311 lbs. / 140 kg

Key Features

  • ¬†Powered by a long-lasting lithium-polymer battery
  • Remote control that allows for both simultaneous steering and driving
  • Can move up to 20 ft/min
  • Loading height of 9.8″
  • 2 year/900 hour warranty

Competitive Edge

  • No cords to deal with
  • No exhaust from propane- able to be used more places
  • Remote control allows you to be your own spotter
  • Less manpower needed overall to move the load
  • No need for a towing device
  • Optional: Lift table to lift the load directly from the ROBOT
  • Optional: Straight line driving function to keep ROBOT moving perfectly straight
  • Move heavy loads up to 88,000 lbs./40 tons safely and autonomously with our Remote-Operated Battery-Operated Transport system the GKS-PERFEKT ROBOT 40
  • Lithium-Polymer battery technology which allows for autonomous transport without external energy sources (electricity, hydraulics, air)
  • Clear transport driveway for increased safety (no hydraulic or pneumatic hoses or power cords are blocking the driveway)
  • Simultaneous steering and driving
  • Secure positioning of the ROBOT 40 from the distance by the remote control
  • Battery packs are exchangeable at the front of the dolly during operation
  • No need for any towing device
  • Low loading height of 9.8"/250 mm
  • Max. load capacity is 88,000 lbs./40 tons.
  • For more information call¬†937.324.8867 today!
